Item

ZSF-9/125-N-0.20

Custom fiber

Fiber Type

Step Index

Core Diameter (μm)

9±1

2 ~ 12

NA

0.20±0.01

0.12， 0.16， 0.21， 0.26

Cut-off Wavelength (μm)

<2.6

-

Loss@1.5μm (dB/m)

<0.1

Cladding Diameter (μm)

123±3

Coating Diameter (μm)

460±30

Core/Cladding Glass

ZBLAN Fluoride Glass

Coating Material

UV curable acrylate

Proof Test

1.25cm Radius

Item

ZMF-400/500-N-0.27

ZMF-160/200-N-0.27

ZMF-100/125-N-0.27

Custom fiber

Fiber type

Step Index

Core dia. (μm)

400±25

160±10

95±5

60 ~ 800

Cladding dia. (μm)

500±25

200±10

123±5

80 ~ 1，000

Coating dia. (μm)

600±30

480±30

460±30

100~ 600

NA

0.27±0.01

0.22， 0.27， 0.30

Loss@2.5μm (dB/m)

<0.1

Core/cladding glass

ZBLAN fluoride glass

Coating material

UV curable acrylate

Proof test

6cm radius

2cm radius

1.25cm radius

TBD

Item

RE dopedSingle Cladding Fiber

RE dopedDouble Cladding Fiber

Fiber type

Step index

Dopant

Pr， Nd， Ho， Er， Dy， Tm， Yb， others

Dopant concentration

500~60，000

Core diameter (μm)

2 ~

Core NA

0.06， 0.12， 0.16， 0.21， 0.26

1st Cladding diameter (μm)

123±3

123， 200， 500

1st Cladding shape

Circular

Circular

Octagonal

Rectangular， etc.

1st Cladding NA

N/A

> 0.5

2nd cladding thickness (μm)

N/A

>30

2nd cladding material

N/A

Fluoro-acrylate

Outer diameter (μm)

460±30

460， 480， 600

Core/Cladding glass

ZBLAN fluoride glass

Coating material

UV curable acrylate

Proof test

1.25cm radius

TBD
